Features

Area of use:

  • Medium and large storage cold rooms or refrigerated warehouses, for the preservation of fresh and frozen products, for aging process, for long time preservation in medium and large processing rooms.

Performance range:

  • Direct Expansion operation: capacity from 7 to 209 kW (R404A, Te= -8° C, T1= 0° C, RH = 85%)
    Fin spacing: 4.5 -7 – 11 – 12mm
  • Brine Operation: capacity from 7 to 240 kW (Glycol 30%, TW1= -10 °C, T1= 0 °C, RH = 85%)
    Fin spacing: 4.5 – 6 – 8 – 12mm
  • Ammonia Operation: capacity from 8 to 262 kW (NH3, Te= -8 °C, T1= 0 °C, RH = 85%)
    Fin spacing: 4.5 -7 – 11 – 12mm
  • ICC carbon dioxide Operation: capacity  from 6 kW to 150 kW (R744, Te= -8° C, Tr= 0°C, RH= 85%)
    Fin spacing: 4,5 – 7 – 11 – 12mm

Fans:

  • Diameter Ø 500, 560, 630 and 800 mm, AC or EC motor

Benefits:

  • Modular design, 1-5 fans
  • Piping in copper or in AISI 304 / 316L
    stainless steel
  • Finned pack available in a wide range of materials
  • Various defrosting systems available
  • Casing: available in aluminium, in AISI 304 / 316L stainless steel or RAL 9010 painted
  • External static pressure 100 Pa (standard): can reach 400 Pa with special tubular fans (new industrial cubic unit cooler)
